Dolphin 4 Data Sheet - Fisheries Product

Environmental

Temperature:

Storage: -55°C to + 125°C Ambient



Operating: -40°C to +85°C Ambient



Altitude:

Max 15,000 m

GSM/GPRS

GSM/GPRS Bands:

GSM 850 MHz



E-GSM 900 MHz



DCS 1800 MHz



PCS 1900 MHz



GSM/GPRS Protocol Stack:

3GPP Release 99



Network Operation Modes:

I to III



Available Protocols:

TCP, UDP, FTP, HTTP



Packet Switched Data Rate:

GPRS multi-slot class 10, Coding scheme CS1-CS4



Up to 85.6 kb/s DL4, Up to 42.8 kb/s UL4



Circuit Switched Data Rate:

Up to 9.6 kb/s DL/UL4 (Transparent and Non-transparent mode)



SMS:

Point-to-point MO and MT



Text and PDU mode



SMS over CSD and PSD



GSM/GPRS Power Class:

Class 4 (33 dBm/2W) for 850/900 MHz



Class 1 (30 dBm/1W) for 1800/1900 MHz



SIM form factor:

Nano SIM (4FF, ETSI TS 102 221 V9.0.0, Mini-UICC)



Antenna:

Internal Antenna

Bluetooth BLE

Type:

v5.0 BLE (compatible with 4.0 - 4.2)



Frequency:

2.4 GHz, 40 channels



Max Transmit Power:

+8 dBm



Receive Sensitivity:

-95 dBm (1Mbps) -103 dBm (125 kbps)



Antenna:

Internal



Encryption:

AES 128 bit using CCM encryption

Satellite communication

Type:

Iridium SBD



Frequency:

1616 MHz to 1626.5 MHz



SBD message transfer average power

0.8 W



Message size:

MO/MT 340/270 bytes



Antenna:

Internal

GPS

Tracking capability:

72 channels



Receiver type:

GPS L1C/A (can be operated concurrently with GLONASS L10F)



SBAS L1C/A



QZSS L1C/A – L1/SAIF



GLONASS L1OF



BeiDou B1l



GALILEO E1B/C



SBAS type:

WAAS, EGNOS, MSAS, QZSS, GAGAN



GPS accuracy:

2.5 m Autonomous, 2.0 m SBAS (CEP, 50%, -130 dBm, > 6 SVs)



GLONASS accuracy:

4.0 m CEP, 50%



Accuracy of time pulse:

RMS 30 ns, 99% 60 ns (GPS)



Sensitivity GPS:

Tracking & Navigation GPS -166 dBm (-167 dBm GPS&GLONASS)



Hot Start -157 dBm (-156 dBm GLONASS) 1 sec TTFF



Cold Start -148 dBm (-145 dBm GLONASS) 26 sec TTFF, 2 sec aided



Max update rate:

10 Hz (5 Hz GPS&GLONASS)



Velocity accuracy:

0.05 m/s



Heading accuracy:

0.3 degrees



Anti-jamming:

Active CW detection and removal, on-board SAW filter



Antenna:

Internal

MCU

Type:

ARM Cortex M4 32-bit processor with FPU



Architecture:

Armv7E-M, Harvard



Speed:

64 Mhz



RAM:

256 Kb



FLASH:

1024 Kb

Operating system

Type:

Mbed OS (RTOS)

Crypto Authentication chip

Type:

ECDH and ECDSA



ECDSA:

FIPS186-3 Elliptic Curve Digital Signature Algorithm



ECDH:

FIPS SP800-56A Elliptic Curve Diffie-Hellman Algorithm



HASH support:

SHA-256 Hash Algorithm with HMAC Option



ID:

Guaranteed Unique 72-bit Serial Number



RNG:

Internal hardware High-quality FIPS Random Number Generator



AES HW acceleration:

AES-128: Encrypt/Decrypt, Galois Field Multiply for GCM



Secure storage:

10Kb EEPROM Memory for Keys, Certificates, and Data

SD Memory Card

Type:

Micro Secure Digital (microSDHC)



Max capacity:

32 GB



File system:

FAT32

Accelerometer

Type:

3-axis MEMS linear accelerometer



Sensitivity:

1 mg/LSB (12bit ADC) @2G range



G Range:

2/4/8 G



Frequency:

12.5 to 400 Hz ODR



Free fall detection

Yes

Pressure sensor

Type:

Atmospheric pressure sensor



Range:

260 to 1260 hPa



Pressure sensitivity:

4096 LSB/hPa



Sample rate:

1-75 Hz

Temperature sensor

Type:

Digital temperature sensor



Accuracy:

± 0.2 °C



Operational temperature range:

-40°C to +125°C

Serial Communication

Type:

USB



Connector:

USB-C (IP-67)



Number of interfaces:

1 (Full Duplex)

Digital Inputs x4

Type:

GPIO 0-40 V(interrupt capable)

Digital outputs x4

Type:

GPIO Ground switching 2 A max per output (PWM capable)

Analogue Digital Converter x2

Type:

12bit max Maximum 1 MSPS @ 12-bit (1.86 MSPS @ 6-bit)

Digital Analogue Converter x2

Type:

12bit max 500 kSPS/s

Connector for I/O, RS-232, Power

Type:

Multiconnector with cap (IP67)

Battery

Type:

LiPO rechargable battery



Voltage:

3.6 VDC



Capacitance:

6 Ah @3V

Solar cell

Type:

Polycrystalline solar cell



Voltage:

4.6 VDC



Total area cm2:

TBD

External Power

Input voltages

2.5 - 42 VDC



Power Available

2.4 A



Type:

Automotive class PSU (protected for +/- 600 V)

Operational messages

Amount:

approx. 2000 messages total from one battery lifecycle



Time:

3 years operations time from one battery lifecycle
